SPECIFICATIONS
| Measurement Range(dBm) | -70~+6dbm | +26dbm~-50dbm |
| Model series: | T-OP400D | T-OP400G |
| With VFL Model No | T-OP400DV05 | T-OP400GV05 |
| With Network test Model No | T-OP400D-RJ | T-OP400G-RJ |
| With VFL, Network test model No | T-OP400DV05-RJ | T-OP400GV05-RJ |
| Wavelength Range | 800~1700nm | |
| OPM Connector | FC/SC/ST(optional) | |
| Connector Type | InGaAs | |
| Standard Wavele | 850/980/1300/1310/1490/1550/1625 /1650 | |
| Uncertainty | ±5% | |
| 650m red light source (optional): | Imw/10mw/20mw/30mw | |
| Network test port(optional) | RJ45 | |
| Display Resolution | Linear Display 0.1%; Logarithmic display 0.01dBm | |
| Working Temp(℃) | -10~+60℃ | |
| Storage Temp(℃) | -30~+70℃ | |
| Auto Switch-off Time(min) | 10min | |
| Battery continuous working time (h) | 72 | |
| Size(mm) | 66*30*112mm | |
| Power | AAA Battery * 2 or 2x AAA Rechargeable battery | |
| Weight (g) | 140/150 | |
