Features
♦ Stable operation with Multi-Action process
♦ Typical cleave angle: 90°± 0.5°
♦ Compact & handy outfit design
♦ High precision cleaving blade with 16 cleave spots
♦ Two Steps for Cleave
♦ Detachable Automatic waste collection box
Specification
♦ Applicable fiber: Single Core Fiber, SM, MM, DS, NZ-DS, EDF, 125um OD of Nude Fiber Cable ♦ Applicable Diameter of Bare fiber:125μm ♦ Applicable Coating Fiber Diameter: φ0.25mm、φ0.9mm、φ2.0mm、φ3.0mm ♦ Cut Length of Fiber Cable：10~16mm (∮0.25mm)﹑10~16mm (∮0.9mm) ♦ Cleave Angle: ≤0.5° ♦ Blade Lifetime: 48000 times ♦ Cleaver Weight with waste collection box : 305g ♦ Temperature: -10℃～+45℃ ♦ Dimensions: 92mm (W) × 57mm (D) × 53mm (H)
